Product Code

Actual Size

Description

HTCHC635

1/4"

STRAIGHT COUPLING STAKED STOP 1/4"

HTCHC794

5/16"

STRAIGHT COUPLING STAKED STOP 5/16"

HTCHC952

3/8"

STRAIGHT COUPLING STAKED STOP 3/8"

HTCHC127

1/2"

STRAIGHT COUPLING STAKED STOP 1/2"

HTCHC1588

5/8"

STRAIGHT COUPLING STAKED STOP 5/8"

HTCHC1905

3/4"

STRAIGHT COUPLING STAKED STOP 3/4"

HTCHC2222

7/8"

STRAIGHT COUPLING STAKED STOP 7/8"

HTCHC2858

1 1/8"

STRAIGHT COUPLING STAKED STOP 1 1/8"

HTCHC3492

1 3/8"

STRAIGHT COUPLING STAKED STOP 1 3/8"

HTCHC4128

1 5/8"

STRAIGHT COUPLING STAKED STOP 1 5/8

HTCHC5397

2 1/8"

STRAIGHT COUPLING STAKED STOP 2 1/8"

HTCHC6666

2 5/8"

STRAIGHT COUPLING STAKED STOP 2 5/8"

HTCHC7937

3 1/8"

STRAIGHT COUPLING STAKED STOP 3 1/8"

HTCHC9207

3 5/8"

STRAIGHT COUPLING STAKED STOP 3 5/8"

HTCHC1048

4 1/8"

STRAIGHT COUPLING STAKED STOP 4 1/8"

HTCHC1302

5 1/8"

STRAIGHT COUPLING STAKED STOP 5 1/8"

HTCHC1556

6 1/8"

STRAIGHT COUPLING STAKED STOP 6 1/8"

HTCHC2064

8 1/8"

STRAIGHT COUPLING STAKED STOP 8 1/8"

Product Code

Actual Size

Description

1

2

HTCH635-318

1/4

1/8

REDUCER FTGXC 1/4"x1/8"

HTCH952-635

3/8

1/4

REDUCER FTGXC 3/8"x1/4"

HTCH127-952

1/2

3/8

REDUCER FTGXC 1/2"x3/8"

HTCH127-635

1/2

1/4

REDUCER FTGXC 1/2"x1/4"

HTCH1588-127

5/8

1/2

REDUCER FTGXC 5/8"x1/2"

HTCH1588-952

5/8

3/8

REDUCER FTGXC 5/8"x3/8"

HTCH1905-1588

3/4

5/8

REDUCER FTGXC 3/4"x5/8"

HTCH1905-127

3/4

1/2

REDUCER FTGXC 3/4"x1/2"

HTCH1905-952

3/4

3/8

REDUCER FTGXC 3/4"x3/8"

HTCH2222-1905

7/8

3/4

REDUCER FTGXC 7/8"x3/4"

HTCH2222-1588

7/8

5/8

REDUCER FTGXC 7/8"x5/8"

HTCH2222-127

7/8

1/2

REDUCER FTGXC 7/8"x1/2"

HTCH2222-952

7/8

3/8

REDUCER FTGXC 7/8"x3/8"

HTCH2858-2222

1 1/8

7/8

REDUCER FTGXC 1 1/8"x7/8"

HTCH2858-1905

1 1/8

3/4

REDUCER FTGXC 1 1/8"x3/4"

HTCH2858-1588

1 1/8

5/8

REDUCER FTGXC 1 1/8"x5/8”

HTCH2858-127

1 1/8

1/2

REDUCER FTGXC 1 1/8"x1/2"

HTCH3492-2858

1 3/8

1 1/8

REDUCER FTGXC 1 3/8”x1 1/8”

HTCH3492-2222

1 3/8

7/8

REDUCER FTGXC 1 3/8"x7/8"

HTCH3492-1588

1 3/8

5/8

REDUCER FTGXC 1 3/8"x5/8”

HTCH4128-3492

1 5/8

1 3/8

REDUCER FTGXC 1 5/8"x1 3/8"

HTCH4128-2858

1 5/8

1 1/8

REDUCER FTGXC 1 5/8"x1 1/8"

HTCH4128-2222

1 5/8

7/8

REDUCER FTGXC 1 5/8"x7/8"

HTCH4128-1588

1 5/8

5/8

REDUCER FTGXC 1 5/8"x5/8"

Product Code

Actual Size

Description

HTCHS635

1/4

90 DEG SR ELBOW 1/4"

HTCHS952

3/8

90 DEG SR ELBOW 3/8"

HTCHS127

1/2

90 DEG SR ELBOW 1/2"

HTCHS1588

5/8

90 DEG SR ELBOW 5/8"

HTCHS1905

3/4

90 DEG SR ELBOW 3/4"

HTCHS2222

7/8

90 DEG SR ELBOW 7/8"

HTCHS254

1

90 DEG SR ELBOW 1"

HTCHS2858

1 1/8

90 DEG SR ELBOW 1 1/8"

HTCHS3492

1 3/8

90 DEG SR ELBOW 1 3/8"

HTCHS4128

1 5/8

90 DEG SR ELBOW 1 5/8"

HTCHS5392

2 1/8

90 DEG SR ELBOW 2 1/8"

HTCHS6666

2 5/8

90 DEG SR ELBOW 2 5/8"

HTCHS7937

3 1/8

90 DEG SR ELBOW 3 1/8"

HTCHS9207

3 5/8

90 DEG SR ELBOW 3 5/8"

HTCHS1048

4 1/8

90 DEG SR ELBOW 4 1/8"

HTCHS1302

5 1/8

90 DEG SR ELBOW 5 1/8"

HTCHS1556

6 1/8

90 DEG SR ELBOW 6 1/8"

HTCHS2064

8 1/8

90 DEG SR ELBOW 8 1/8"

Product Code

Actual Size

Description

HTCHL476

3/16

90 DEG LR ELBOW 3/16"

HTCHL635

1/4

90 DEG LR ELBOW 1/4"

HTCHL794

5/16

90 DEG LR ELBOW 5/16"

HTCHL952

3/8

90 DEG LR ELBOW 3/8"

HTCHL127

1/2

90 DEG LR ELBOW 1/2"

HTCHL1588

5/8

90 DEG LR ELBOW 5/8"

HTCHL1905

3/4

90 DEG LR ELBOW 3/4"

HTCHL2222

7/8

90 DEG LR ELBOW 7/8"

HTCHL2858

1 1/8

90 DEG LR ELBOW 1 1/8"

HTCHL3175

1 1/4

90 DEG LR ELBOW 1 1/4"

HTCHL3492

1 3/8

90 DEG LR ELBOW 1 3/8"

HTCHL4128

1 5/8

90 DEG LR ELBOW 1 5/8"

HTCHL5397

2 1/8

90 DEG LR ELBOW 2 1/8"

HTCHL6666

2 5/8

90 DEG LR ELBOW 2 5/8"

HTCHL7937

3 1/8

90 DEG LR ELBOW 3 1/8"

HTCHL9207

3 5/8

90 DEG LR ELBOW 3 5/8"

HTCHL1048

4 1/8

90 DEG LR ELBOW 4 1/8"

Product Code

Actual Size

Description

HTCHE635

1/4

45 DEG ELBOW CXC 1/4"

HTCHE952

3/8

45 DEG ELBOW CXC 3/8"

HTCHE127

1/2

45 DEG ELBOW CXC 1/2"

HTCHE1588

5/8

45 DEG ELBOW CXC 5/8"

HTCHE1905

3/4

45 DEG ELBOW CXC 3/4"

HTCHE2222

7/8

45 DEG ELBOW CXC 7/8"

HTCHE2858

1 1/8

45 DEG ELBOW CXC 1 1/8"

HTCHE3492

1 3/8

45 DEG ELBOW CXC 1 3/8"

HTCHE4128

1 5/8

45 DEG ELBOW CXC 1 5/8"

HTCHE5392

2 1/8

45 DEG ELBOW CXC 2 1/8"

HTCHE6666

2 5/8

45 DEG ELBOW CXC 2 5/8"

HTCHE7937

3 1/8

45 DEG ELBOW CXC 3 1/8"

HTCHE9207

3 5/8

45 DEG ELBOW CXC 3 5/8"

HTCHE1048

4 1/8

45 DEG ELBOW CXC 4 1/8"

HTCHE1302

5 1/8

45 DEG ELBOW CXC 5 1/8"

HTCHE1556

6 1/8

45 DEG ELBOW CXC 6 1/8"

Product Code

Actual Size

DESCRIPTION

HTCHU952

  3/8

U BEND CXC 3/8"

HTCHU127

  1/2

U BEND CXC 1/2"

HTCHU1588

  5/8

U BEND CXC 5/8"

HTCHU1905

  3/4

U BEND CXC 3/4"

HTCHU2222

  7/8

U BEND CXC 7/8"

HTCHU2858

1 1/8

U BEND CXC 1 1/8"

HTCHU3492

1 3/8

U BEND CXC 1 3/8"

HTCHU4128

1 5/8

U BEND CXC 1 5/8"

HTCHU5392

2 1/8

U BEND CXC 2 1/8"

Product Code

Actual Size

Description

HTCHT476

3/16

TEE EQUAL 3/16"

HTCHT635

1/4

TEE EQUAL 1/4"

HTCHT794

5/16

TEE EQUAL 5/16"

HTCHT952

3/8

TEE EQUAL 3/8"

HTCHT127

1/2

TEE EQUAL 1/2"

HTCHT1588

5/8

TEE EQUAL 5/8"

HTCHT1905

3/4

TEE EQUAL 3/4"

HTCHT2222

7/8

TEE EQUAL 7/8"

HTCHT2858

1 1/8

TEE EQUAL 1 1/8"

HTCHT3492

1 3/8

TEE EQUAL 1 3/8"

HTCHT4128

1 5/8

TEE EQUAL 1 5/8"

HTCHT5392

2 1/8

TEE EQUAL 2 1/8"

HTCHT6666

2 5/8

TEE EQUAL 2 5/8"

HTCHT7937

3 1/8

TEE EQUAL 3 1/8"

HTCHT9207

3 5/8

TEE EQUAL 3 5/8"

HTCHT1048

4 1/8

TEE EQUAL 4 1/8"

HTCHT1302

5 1/8

TEE EQUAL 5 1/8"

HTCHT1556

6 1/8

TEE EQUAL 6 1/8"

Copper Alloy No.

Chemical Composition

Temper

Mechanical Properties

Tensile strength (Mpa)

Elongation (%)

Grain Size (mm)

CU%

P%

C12200

≥99.90

0.015-0.040

H58

290

/

/
