Application: Fluid transmission of cool and hot water, drinking water.
Note: the same outside diameter with different wall thickness also available.
Standard: ASTM B88, EN1057, AS 1432，NZS 3501
Package：Each piece end capped, Bundled with plastic bag; then put in the wooden box or container.

Product code and size

Product Code	Description
HTCBW952	COPPER WATER TUBE 1/4”(3/8”)TYPE K, L, M
HTCBW1270	COPPER WATER TUBE 3/8”(1/2”) TYPE K, L, M
HTCBW1588	COPPER WATER TUBE 1/2”(5/8”) TYPE K, L, M
HTCBW1905	COPPER WATER TUBE 5/8”(3/4”) TYPE K, L, M
HTCBW2223	COPPER WATER TUBE 3/4”(7/8”) TYPE K, L, M
HTCBW2858	COPPER WATER TUBE 1”(1-1/8”) TYPE K, L, M
HTCBW3493	COPPER WATER TUBE 1-1/4”(1-3/8”) TYPE K, L, M
HTCBW4128	COPPER WATER TUBE 1-1/2”(1-5/8”) TYPE K, L, M
HTCBW5398	COPPER WATER TUBE 2”(2-1/8”) TYPE K, L, M
HTCBW6668	COPPER WATER TUBE 2-1/2”(2-5/8”) TYPE K, L, M
HTCBW7938	COPPER WATER TUBE 3”(3-1/8”) TYPE K, L, M
HTCBW9208	COPPER WATER TUBE 3-1/2”(3-5/8”) TYPE K, L, M
HTCBW10478	COPPER WATER TUBE 4”(4-1/8”) TYPE K, L, M

Chemical and mechanical property

Copper Alloy No.	Chemical Composition		Temper	Mechanical Properties
				Tensile strength (Mpa)	Elongation (%)	Grain Size (mm)
	CU%	P%
C12200	99.9	0.015-0.040	H58	≥ 250	∕	∕
			O50	≥ 205	∕	0.025
			O60	≥ 205	∕	0.040

COPPER WATER PIPE
